日本ACT压力开关BP-F8-250-CK原装进口一级代理

BP-F8型是使用布尔登管和标准微型开关的通用型压力开关，具有独特的差压调整机构，能大范围地进行开关控制。

产品特点

1、易于改变设定值。（也可外部设定）

2、差压（差动）可变换

3、使用标准微型开关，故电气额定大。

4、压力范围丰富。

主要规格

1、使用流体：石油类工作有（非腐蚀性）※一部分也可以用空气、蒸汽、水。

2、压力刻度范围：0～50MPa

3、工作指示灯：备有氖灯供客户特别订货。

4、接管管径：5MPa一下Rc1/4 10MPa以上G1/2※备有G3/8供客户特别订货。

5、设定进度：设定范围最大值（全刻度）的±2%以内

6、容许环境温度：-20～+60℃

7、容许流体温度：-20～+70℃

8、喷漆：标准 芒塞尔7.5BG7/2

9、外壳材质：铝压铸

BV-F8型真空开关是使用特殊布尔登管和高灵敏度微型开关的通用型开关，具有差压调整机构，能进行上下限双接点控制。

产品特点

1、设定范围大，调整更方便。

2、标准带有真空增加时（上限）设定刻度。

3、从低真空到高真空，差压（差动）一直恒定。

4设定误差小，使用寿命长。

主要规格

1、使用流体：非腐蚀性的流体、气体（若为腐蚀性，请另行知会本公司）

2、接管管径：标准Rc1/4

3、设定进度：设定范围最大值（全刻度）的±2%以内

4、容许环境温度：-20℃～+60℃

5、容许流体温度：-20℃～+70℃

6、喷漆：标准 芒塞尔7.5BG7/2

7、外壳材质：铝压铸

8、容许内压脉冲：差压（差动）的约50%以内

9、容许振动：上下2G 前后2G 左右0.8G

10、电气使用寿命：100万次以上

11、机械使用寿命：100万次以上

12、真空刻度范围：0～-0.1MPa

   上限设定0.0067～0.01MPa

   下限设定0.0033～0.0098MPa

13、重量：约1.6kg
